Shafted 2 color rotogravure printing machine is designed for two side online printing width up to 1300 mm and print length range 450 – 650 mm.

An independent servo motor and gearbox for each unit provided high accuracy transmission and accurate printing . each printing unit has a independent dryer and blower for high speed.

First unit used as a infeed unit and speed of print machine automatically synchronized with the extruder blow film machine .

Long register control is motorized and side register control is manual in this machine.

• Shafted and electronic line shaft (ELS)
• Adjustable doctor blade in 2 direction
• Electronic long register control system
• Drying chambers with electrical heaters and delivery fans
• Stainless steel ink pan and ink tank with related pump
• Fully integrated operator-machine interface system

Technical specifications
Speed	120 m/min
Web width	650-1250 mm
Printing repeat	450-650 mm
Drying inside length	1.6 m
